Panel
Panel Type
IPS
Panel Size
64.5"
Max. Resolution
UHD 3840 x 2160
Pixel Pitch
0.372 mm
Brightness
400 cd/m²
Contrast Ratio
1200:1
Viewing Angle (H/V)
178°/178°
Display Colour
1.07G colors (10bits).
Response Time
5 ms
Surface Treatment
Haze 25 %
2H
Anti-Glare
Frequency
Frequency (H)
30KHz-135KHz
Frequency (V)
30Hz-76Hz
Signal Input
HDMI
2.1 x 1
Signal Output
HDMI
2.1 x 1
External Control
RS232 In
9-Pin D-Sub
LAN
RJ45 x 2
Embedded Player
OS
Android 13.0
CPU
Cortex A76+A55
Memory
8G
Storage
128 G
Other Connectivity
USB
USB 3.0 x 5 (Media Playback) Type-C(PD:60W)
OPS Slot
Yes
Audio
Audio Out
S/PDIF
Internal Speakers
15W x 2
Touch Screen
Technology
Infrared Touch Frame
Positional Accuracy
±1 mm
Panel Interface
USB (Type-B)
Single Touch Plug & Play
Windows 2000/XP/Vista/CE 6.0 macOS
Multi-touch Plug & Play
40 point touch for Windows 7/8/10/11
20 points for Android/Linux (kernel 3.5 above) Chrome 39 or above
Multi-touch Support by Driver
20 point touch for macOS (supported by UPDD driver)
Power
Power Supply
Internal
Power Requirements
AC100~240
50Hz~60Hz
On Mode
185W (On)
Standby Mode
< 0.5W
Off Mode
0W
Glass
Thickness
3.2mm
Gloss
≤ 0.3um
Haze
3%~8%
Pencil Hardness
8H
IK Rating
IK08
MOHS Hardness
5
Operating Conditions
Temperature
0°C-40°C (32°F-104°F)
Humidity
20%-80% (non-condensing)
Storage Conditions
Temperature
-20°C-60°C (-4°F-140°F)
Humidity
10%-80% (non-condensing)
Mounting
VESA FPMPMI
Yes (600 x 400 mm)
Dimensions
Packaging (W x H x D)
1600.0 x 220.0 x 1045.0 mm (63.0" x 8.7" x 41.1")
Product with Bracket (W x H x D)
1482.1 x 929.9 x 117.5 mm (58.4" x 36.6" x 4.6")
Product w/o Bracket (W x H x D)
1482.1 x 929.9 x 86.0 mm (58.4" x 36.6" x 3.4")
Weight
Packaging
49.5 kg (109.1 lb)
Product with Bracket
43.3 kg (95.5 lb)
Product w/o Bracket
40.5 kg (89.3 lb)
Regulation Approval
Certifications & Compliance
CE
LVD
RoHS
WEEE
REACH
Integrated Camera
Camera Resolution
8M
Camera Pixel
3840*2160(30fps)
Microphone
8-Array
Accessories
Supplied
Batteries
HDMI Cable
Power Cord
Quick Start Guide
Remote Control
USB Cable
Wall Mount
Wi-Fi / Bluetooth Module
Active Pen
Stylus
Optional Accessories
Ceiling Mount (Landscape only)
CMP-01 + LMK-01
Wall Mount (Landscape only)
LMA-02
LMK-01
LMK-03
Floor Mount (Landscape only)
FMC-06
FMC-07
